High-power VTX-F2-72 video transmitter for FPV drones with 72 channels and 3000mW output

TX-F2-72 Video Transmitter (4.9G / 5.8G / 6G 72CH 3W) - Image 2

TX-F2-72 Video Transmitter (4.9G / 5.8G / 6G 72CH 3W) - Image 3

TX-F2-72 Video Transmitter (4.9G / 5.8G / 6G 72CH 3W) - Image 4

TX-F2-72 Video Transmitter (4.9G / 5.8G / 6G 72CH 3W)

5 products sold in last 18 hours

Selling fast! Over 4 people have in their cart

he VTX-F2-72 is a high-performance video transmitter designed for FPV drones, offering 72 channels across 4.9GHz, 5.8GHz, and 6GHz bands with a powerful 3000mW output. It features low latency, strong anti-interference, and temperature-controlled active cooling, making it ideal for racing, aerial photography, and long-range flights.

Constructed with a CNC aluminum casing and a built-in turbofan, it ensures stable, high-power transmission. The unit supports IRC Tramp protocol and OSD parameter tuning, and includes multiple output levels (PIT, 25mW, 400mW, 800mW, 3000mW). It’s lightweight, compact, and suitable for both professional and hobbyist FPV drone builders.

Available at Mallofaviation, a trusted FPV drone store in India, it’s a top choice for users searching for:

Cheapest drone motor
Best VTX in India
Buy drone parts online
Affordable FPV accessories

This transmitter is compatible with 2S to 8S battery setups. It is a reliable and budget-friendly choice for FPV enthusiasts.

20 people are viewing this right now

Estimated Delivery : Up to 4 business days
Free Shipping & Returns : On all orders over $200

Guaranteed Safe And Secure Checkout

Description
Reviews (0)

The VTX-F2-72 is a high-performance video transmitter designed for FPV drones, long-range quads, and racing builds. Ideal for those searching for cheap drone motor alternatives, top FPV accessories in India, or the best drone motor and VTX combo for stable and high-powered performance.

Whether you’re browsing the cheapest drone parts online, exploring FPV drone stores, or comparing the best drone transmitters in India, this unit from Mallofaviation delivers uncompromised quality at a competitive price.

✅ Key Features:

Ultra-high transmission power: Over 3000mW
Lightweight and compact design
Strong anti-interference & low latency
CNC Aluminum alloy casing with active cooling micro turbofan
IRC Tramp Protocol, OSD parameter control
Ideal for: FPV flights, aerial photography, racing, professional drone filming
Supports 4.9GHz, 5.8GHz, 6GHz frequency bands

📦 Full Technical Specifications Table

Item	Specification
Input Voltage	DC 7V-36V (2~8S)
Output Voltage	5V±0.5V Out（MAX 500mA Input Voltage >7.2V)
Channel Number	72CH (4867MHz-6100MHz, one frequency at a time)
Transmitter Power	PIT Mode, 25mW, 400mW, 800mW, 3000mW
Control Protocol	IRC Tramp, OSD Adjustable
Modulation Type	FM
Frequency Control	PLL
Frequency Stability	±100KHz (Typ.)
Frequency Precision	±200KHz (Typ.)
Signal-to-Noise Ratio	>70dBc
Antenna Impedance	50 Ohms
Antenna Interface	MMCX
Video Format	PAL / NTSC
Video Output	1V±0.2Vp-p type (CVBS)
Audio Input	MIC Sound Pickup (Audio Carrier 6.5M)
Operating Temp.	-10°C to +60°C
Dimensions	38.5mm x 35.5mm x 10.76mm
Mounting Holes	30.5mm x 30.5mm (M3 mounting)
Weight	15.6g (excluding antenna)

🛒 Why Buy from Mallofaviation?

Trusted online FPV store in India
One-stop shop for budget drone parts
Offers on best motors, ESCs, flight controllers, and VTX units
Great option for drone hobbyists, FPV racers, and DIY drone builders
Competitive pricing for cheapest FPV motors and transmitters in India

Perfect for:
✔️ Long-range FPV setups
✔️ High-quality video transmission
✔️ Affordable FPV drone builds
✔️ Users looking for the best budget drone motor and VTX combo in India
