Skyzone Cobra X V4 5.8GHz FPV Goggles w/ SteadyView Receiver

Skyzone Cobra X V4 FPV Goggles – Professional 5.8GHz Viewing System

The Skyzone Cobra X V4 FPV Goggles are designed for pilots who require stable signal reception, high-resolution display clarity, and long operating endurance. Built around a 5.8GHz SteadyView receiver system, these goggles merge dual signals into a single stable output. This signal blending reduces image tearing and rolling, especially in RF-challenging environments.

The integrated LCD display provides a crisp 1280×720 resolution with switchable 4:3 and 16:9 aspect ratios. This flexibility ensures compatibility with most analog FPV cameras and transmission systems. The high luminance screen enhances contrast and detail visibility during racing, freestyle flying, and long-range exploration.

SteadyView Receiver Technology in Skyzone Cobra X V4 FPV Goggles

The SteadyView receiver merges signals from two antennas into one optimized feed. Instead of switching between antennas like traditional diversity systems, it combines data streams to maintain image stability. This significantly improves clarity during weak signal conditions or high-speed maneuvering.

High-Resolution Display & 60FPS DVR

The upgraded DVR module records in H264 format at 60 frames per second. Recording at higher frame rates results in smoother playback and improved flight review analysis. The DVR supports SD cards up to 128GB, allowing extended recording sessions during competitions or long-distance flights.

User Interface & Navigation

The redesigned operating system supports ten selectable languages. A side-mounted shuttle wheel allows pilots to navigate settings quickly without removing the goggles. Adjustments such as brightness, aspect ratio, and channel selection can be performed efficiently during field operations.

Built-In Headtracker & Power Flexibility

An integrated 3-axis accelerometer and gyroscope provide accurate headtracking functionality for supported systems. The goggles support multiple power options including a single 18650 battery, 2–6S LiPo input, USB 5V, or DC input ranging from 6.5V to 25.2V. The upgraded power management board improves runtime and operational stability.

For pilots exploring alternative models within the same ecosystem, you may also consider the SKYZONE Cobra SD, or browse the complete FPV Goggles Collection to compare viewing systems.

Technical Specifications

• Resolution: 1280×720 LCD
• Aspect Ratio: 4:3 / 16:9 Switchable
• Receiver: SteadyView V3.3
• DVR: H264, 60FPS, MOV 6Mbps
• Headtracker: 3-axis Accelerometer & Gyroscope
• Power Input: 18650 / 6.5–25.2V DC / USB 5V
• Power Consumption: 12V 0.63A / 5V 1.5A

For technical understanding of 5.8GHz analog FPV frequency systems, refer to First-Person View (FPV) Technology Overview. This explains the transmission principles used in analog FPV environments.

The Skyzone Cobra X V4 FPV Goggles combine display clarity, receiver stability, DVR capability, and ergonomic usability. They are suitable for racing drones, freestyle builds, and long-range FPV pilots who require dependable 5.8GHz viewing performance.
